PIMS is to provide a current status report in respect of physical parts (generally pipes) of the pipeline. Items included in addition to pipes are bends, valves, assemblies, joints and tees.
During the lifetime of the IOCL pipelines, PIMS will keep track of the information related to the constituent parts of the IOCL pipelines (Pipes, Bends, Valves, Assemblies, Joints, Tees, Reducers) readily accessible.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
Business ObjectiveLaying 36” OD, 1034 Km (approx.) Cross Country Pipeline from Churwa (Gujarat) to Panipat (Haryana) for New Mundra Panipat Pipeline (P-25) Project)
Project Name : New Mundra Panipat Pipeline
| Project Name | New Mundra Panipat Pipeline | |
| Project Length | 1108 Km | |
| Material Specification | API 3L Grade X 70, LSAW/HSAW | |
| Diameter | 36” | |
| Wall Thickness (mm) | 15.47, 19.05, 23.83 mm | |
| Design Pressure | ||
| Design Temperature | ||
| Coating | 3LPE coating | |
| Client | Indian Oil Corporation Limited | |
| Contractor(Gorup-01) | JSIW Infra pvt ltd. |  |
| Contractor(Gorup-02) | MEGHA ENGINEERING |  |
| Contractor (Gorup-03) | Ace Pipeline-LC Infra Consortium (Ace) |  |
| Contractor(Gorup-04) | M/s Kalpataru Projects International Limited |  |
| Contractor (Gorup-05) | M/s Corrtech International Ltd. |  |
| PIMS | Unistal Systems Pvt. Ltd. |  |
| Start Date | 15.07.2023 | |
| End Date | 14.10.2024 |
| Spread | Section Name | Chainage From | Chainage To | Length |
|---|---|---|---|---|
| Spread-1 | CHURWA - NH15 (IPS1) | 74 | 167 | 93 |
| Spread-2 | CHURWA - NH15 (IPS1) | 167 | 264 | 97 |
| Spread-3 | GJ/RJ BORDER - (NIMBLAKISHANGARH) BT Road | 264 | 374 | 110 |
| Spread-4 | GJ/RJ BORDER - (NIMBLAKISHANGARH) BT Road | 374 | 485 | 111 |
| Spread-5 | (NIMBLA KISHANGARH) BT Road- PMGSY ROAD (Kuwal-Kiroda) | 485 | 598 | 113 |
| Spread-6 | (NIMBLA KISHANGARH) BT Road- PMGSY ROAD (Kuwal-Kiroda) | 598 | 712 | 114 |
| Spread-7 | PMGSY ROAD (Kuwal Kiroda) - RJ/HR | 712 | 825 | 113 |
| Spread-8 | PMGSY ROAD (Kuwal Kiroda) - RJ/HR | 825 | 939 | 114 |
| Spread-9 | RJ/HR BORDER PANIPAT | 939 | 1024 | 85 |
| Spread-10 | RJ/HR BORDER PANIPAT | 1024 | 1109 | 85 |
�
Services By Unistal System Pvt. Ltd.
